Product Description
Specifications
Manufacturer: Kramer Electronics LTD
Manufacturer Website Address: http://www.kramerelectronics.com
Brand Name: Kramer
Product Line: MegaTOOLS
Product Model: VP-427A
Product Name: HDBaseT to HDMI & Audio ProScale Receiver/Scaler
Marketing Information:
Product Type: Video Extender Receiver
Technical Information
Connectivity Technology: Wired
Number of Output Devices Supported: 1
Maximum Operating Distance: 229.66 ft
Video
Maximum Video Resolution: 1920 x 1200
Interfaces/Ports
Network (RJ-45): Yes
HDMI Out: Yes
USB: Yes
Number of Network (RJ-45) Ports: 1
Number of USB Ports: 1
Number of HDMI Outputs: 1
Physical Characteristics
Receiver Height: 1"
Receiver Width: 7.38"
Receiver Depth: 4.53"
Receiver Weight (Approximate): 1.10 lb
Manufacturer: Kramer Electronics LTD
Manufacturer Website Address: http://www.kramerelectronics.com
Brand Name: Kramer
Product Line: MegaTOOLS
Product Model: VP-427A
Product Name: HDBaseT to HDMI & Audio ProScale Receiver/Scaler
Marketing Information:
The Kramer VP-427A is a receiver/scaler for HDBaseT twisted pair, HDMI, bidirectional RS-232 and IR signals. The unit receives an HDBaseT signal that it converts to HDMI, IR and RS-232 signals. It up- or down-scales the picture to match the resolution of the HDMI monitor. It includes a simultaneous analog audio output of the embedded HDMI audio.
- Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel).
- Bidirectional RS-232 Port - For embedding/de-embedding control commands in the HDBaseT data stream.
- Infrared Input and Output Ports - For controlling devices over the HDBaseT data stream.
- System Range - Up to 70m (230ft).
- Embedded Audio - Support for LPCM 2CH.
- Analog Audio Output - Includes a simultaneous unbalanced stereo audio output of the embedded HDMI audio.
- Constant Output Sync - Even when the input video signal is lost or interrupted.
- ProcAmp Control - Contrast, brightness, fine tune & R, G, B level/gain.
- On-Screen Display (OSD) - For easy setup and adjustment, accessible via the front-panel buttons.
- Non-Volatile Memory - Saves final settings.
- Freeze Button.
- USB Port - For upgrading firmware.
APPLICATIONS
- Home theater
- Presentation and multimedia
- Rental and staging
Product Type: Video Extender Receiver
Technical Information
Connectivity Technology: Wired
Number of Output Devices Supported: 1
Maximum Operating Distance: 229.66 ft
Video
Maximum Video Resolution: 1920 x 1200
Interfaces/Ports
Network (RJ-45): Yes
HDMI Out: Yes
USB: Yes
Number of Network (RJ-45) Ports: 1
Number of USB Ports: 1
Number of HDMI Outputs: 1
Physical Characteristics
Receiver Height: 1"
Receiver Width: 7.38"
Receiver Depth: 4.53"
Receiver Weight (Approximate): 1.10 lb
