Product Description
Specifications
- Mfr Part Number: TUF Z390-PLUS GAMING (WI-FI)
- CPU: LGA1151
- Supports Intel Core 9000 series, 8th Generation Intel Core i7/ i5/ i3/ Pentium/ Celeron Processors
- Supports 14nm CPU
- Supports Intel Turbo Boost Technology 2.0
- Chipset: Intel Z390
- Memory: 4x DDR4-4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2666/ 2400/ 2133 MHz DIMM Slots, Dual Channel, Non-ECC, Unbuffered, Max Capacity of 64GB
- Slots: 1x PCI-Express 3.0/2.0 x16 Slot (supports x16, x8+x4+x4), 1x PCI-Express 3.0/2.0 x16 Slot (runs at x4), 4x PCI-Express 3.0/2.0 x1 Slots
- Multi-Graphics: Supports AMD CrossFireX Technology
- Storage:
- SATA: 6x SATA3 Ports, Support RAID 0, 1, 5, 10
- M.2: 2x M.2 Ports (w/ M key), one supports type 2242/ 2260/ 2280 storage devices & SATA &PCI-Express x4 mode, one supports type 2242/ 2260/ 2280/ 22110 storage devices & SATA & PCI-Express x4 mode
- Audio: Realtek S1200A 8-Channel High Definition Audio CODEC
- LAN: Intel I219-V Gigabit Ethernet Controller, Intel Wireless-AC 9560 2x2 Wi-Fi with MU-MIMO 802.11a/b/g/n/ac Wireless LAN (2.4/5 GHz), Bluetooth V5.0
- Ports: 2x USB 3.1 Gen 2 Ports (Type-A rear), 8x USB 3.1 Gen 1 Ports (4 Type-A rear, 4 at mid-board), 3x USB 2.0/1.1 Ports (at mid-board), 1x PS/2 keyboard Port, 1x PS/2 mouse Port, 1x DisplayPort, 1x HDMI Port, 1x RJ45 LAN Port, 2x Wi-Fi antenna Ports, Audio I/O Jacks
- Power Connector: 1x 24pin EATX Power Connector, 1x 8pin EATX 12V Power connector
- Form Factor: ATX, 12.0 x 9.6 inch / 30.5 x 24.4 cm
