Product Description
Specifications
- Mfr Part Number: AS5010T
- Hardware:
- CPU: Intel Celeron Processor (2.41GHz, burst up to 2.58GHz, Dual-Core)
- Memory: 1GB DDR3L SODIMM (Expandable up to 8GB)
- HDD: 10x 2.5" or 3.5" SATA II / III HDD or SSD
- Expansion: 3x USB 3.0 Ports, 2x USB 2.0 Ports, 2x eSATA Ports
- Network: 4x Gigabit Ethernet Ports
- LCD Panel
- Output: 1x HDMI Port, 1x S/PDIF
- System Fan: 2x 120mm Fans
- Infrared Receiver
- Input Power Voltage: 100~240 V AC
- Eco-Friendly Design:
- System Automatically Enters Sleep Mode (Schedule S3)
- Auto-Standby for Both Internal and External Disks
- Auto Fan Control
- LED Night Mode
- Power Schedule: On, Off, Restart, and Sleep
- Software:
- Operating System: ADM 2.0 Onwards, Built-in App Central for Various Apps
- Supported OS:
- Windows XP, Vista, 7, 8, Server 2003, Server 2008, Server 2012
- Mac OS X 10.6 Onward
- UNIX, Linux, and BSD
- Supported Browsers: Internet Explorer 9 Onwards, FireFox, Chrome, Safari
- Network Protocols: CIFS/SMB, AFP, NFS, FTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, SMB 2.0, TFTP, Proxy
- File System:
- Internal Disk: EXT4
- External Disk: FAT32, NTFS, EXT3, EXT4, HFS+
- Storage Management:
- Support Multiple Volumes with Spare Disks
- Volume Type: Single disk, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
- Support for Online RAID Level Migration
- Support for Online RAID Capacity Expansion
- iSCSI:
- Maximum Targets: 256
- Maximum LUNs: 256
- Target Masking
- LUN Mapping
- ISO File Mounting
- Supports MCS
- Persistent (SCSI-3) Reservations
- Disk Management:
- Scheduled Bad Block Scans
- Scheduled S.M.A.R.T Scans
- Network:
- TCP/IP (IPv4 & IPv6)
- Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
- Jumbo Frame (MTU)
- VLAN
- Cloud Connect
- Wireless Network³
- DDNS and EZ-Router
- Supports Wake-on-LAN (WOL)
- Backup Solutions:
- Rsync (Remote Sync) Backup
- Cloud Backup
- FTP Backup
- External Backup
- One Touch Backup
- System Administration:
- Log Type: System Log, Connection Log, File Access Log
- Real-time Online User Monitor
- Real-time System Monitor
- Network Recycle Bin
- User Quota
- Virtual Drive (ISO Mounting, Maximum 16)
- UPS Support
- Access Control:
- Maximum Number of Users: 4096
- Maximum Number of Groups: 512
- Maximum Number of Shared Folders: 512
- Maximum Number of Concurrent Connections: 512
- Supports Windows Active Directory
- Security:
- AES 256-Bit Folder Encryption
- Firewall: Prevent Unauthorized Access
- Network Defender: Prevent Network Attacks
- Alert Notifications: E-mail, SMS
- Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
- Featured Apps:
- ACL
- iTunes Server
- Antivirus
- Mail Server
- ASUSTOR Portal
- Photo Gallery
- XBMC
- Download Center
- Surveillance Center
- Dropbox
- Sounds Good
- File Explorer
- FTP Explorer
- Takeasy
- Google Drive
- UPnP Media Server
- HiDrive
- VPN Client
- LooksGood
- VPN Server
- Power Consumption: 74.2W (Operation), 35.2W (Disk Hibernation), 3.2W (Sleep Mode)
- Certifications: FCC, CE, VCCI, BSMI, C-TICK
- Dimensions (WxDxH): 293.0 x 230.0 x 215.5 mm
- Weight: 13.89 lbs / 6.3 kg
