Product Description
Main Specifications:
| Device Type | Security appliance |
| Form Factor | Rack-mountable - 2U |
| RAM | 12 GB |
| Flash Memory | 2 GB |
| Ports Qty | 8 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Firewall throughput : 10 Gbps VPN throughput : 2 Gbps Connection rate : 125000 connections per second Firewall + intrusion prevention throughput : 3 Gbps |
| Capacity | Concurrent sessions : 1000000 IPSec VPN peers : 10000 Virtual interfaces (VLANs) : 250 SSL VPN peers : 2 Nodes : unlimited |
| Power | AC 120/230 V ( 50/60 Hz ) |
| Dimensions (WxDxH) | 48.3 cm x 67.3 cm x 8.8 cm |
General | |
| Device Type | Security appliance |
| Height (Rack Units) | 2U |
| Installed Modules Qty (Max) | 1 ( 2 ) |
| Width | 48.3 cm |
| Depth | 67.3 cm |
| Height | 8.8 cm |
Networking | |
| Form Factor | Rack-mountable |
| Ports Qty | 8 |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | IPSec |
| Performance | Firewall throughput : 10 Gbps VPN throughput : 2 Gbps Connection rate : 125000 connections per second Firewall + intrusion prevention throughput : 3 Gbps |
| Capacity | Concurrent sessions : 1000000 IPSec VPN peers : 10000 Virtual interfaces (VLANs) : 250 SSL VPN peers : 2 Nodes : unlimited |
| Features | Firewall protection, VPN support, load balancing, VLAN support |
| Encryption Algorithm | Triple DES, AES |
Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1 |
Processor / Memory / Storage | |
| RAM | 12 GB |
| Flash Memory | 2 GB |
Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V ( 50/60 Hz ) |
Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
Expansion / Connectivity | |
| Expansion Slots | 2 (total) / 1 (free) x expansion slot 2 (total) / 2 (free) x |
| Interfaces | 2 x 1000Base-T (management) - RJ-45 2 x USB 2.0 - Type A 1 x management - RJ-45 1 x management 8 x 1000Base-T - RJ-45 |
