Product Description
| Management features | |
|---|---|
| Switch type | Managed network switch |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Networking | |
| Networking standards | IEEE 802.1D,IEEE 802.1p,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Full duplex | Yes |
| Port mirroring | Yes |
| DHCP client | Yes |
| 10G support | No |
| Data transmission | |
| MAC address table | 8000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 16 Gbit/s |
| Number of VLANs | 16 |
| Maximum data transfer rate | 1 Gbit/s |
| Protocols | |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Supported network protocols | HTTP |
| Design | |
| Colour of product | Black |
| LED indicators | Yes |
| Certification | FCC Part15 Class B, CE Class A, UL, cUL, CE, CB |
| Technical details | |
| Colour of product | Black |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Certificates | |
| Certification | FCC Part15 Class B, CE Class A, UL, cUL, CE, CB |
| Indication | |
| Power LED | Yes |
| LED indicators | Yes |
| System requirements | |
| Compatible operating systems | Windows XP + |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Weight | 14.8 oz (420 g) |
| Other features | |
| Dimensions (WxDxH) | 5.12 x 5.12 x 1.12" (130 x 130 x 28.5 mm) |
| Connectivity technology | Wired |
| Power LED | Yes |
| Authentication method | RADIUS |
