Product Description
Specifications
- Mfr Part Number: 100-W1-0500-KR
- Features:
- Heavy-duty Protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection) and OTP (Over Temperature Protection)
- Quiet and Intelligent Auto Fan for near-silent operation
- Maximum Power: 500 W
- Input:
- Voltage: 100 ~ 240 VAC
- Current: 8 A
- Frequency Range: 50 ~ 60 Hz
- Type: ATX12V
- Efficiency: 80% Typical
- Fan: 1x 120mm Fan
- Output: +3.3V @ 24A, +5V @ 20A, +12V @ 40A, +5VSB @ 3A, -12V @ 0.3A
- Connectors: 1x 24Pin ATX Main Power Connector, 1x 8Pin EPS12V Power Connector, 2x 6+2Pin PCI-Express Connectors, 6x SATA Connectors, 3x 4pin Molex Connectors, 1x Floppy Connector
- Approvals: TUV, cUL, UL, CE, FCC, WEEE, RoHS
- Dimensions (WxLxH): 150.0 x 140.0 x 85.0 mm
- Weight: 4.0 lbs
