Product Description
| Processor | |
|---|---|
| Stepping | S0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake |
| Bus type | DMI3 |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,2133,2400 MHz |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 51 W |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| Maximum number of PCI Express lanes | 16 |
| Memory channels supported by processor | Dual |
| ECC supported by processor | No |
| Processor cache type | Smart Cache |
| Conflict Free processor | Yes |
| Processor cache | 3 MB |
| Processor frequency | 3.9 GHz |
| Processor model | i3-7100 |
| Number of processors installed | 1 |
| System bus rate | 8 GT/s |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| Processor cores | 2 |
| PCI Express slots version | 3.0 |
| Processor family | 7th gen Intel® Core™ i3 |
| Memory | |
| Internal memory | 8 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| Maximum internal memory | 16 GB |
| Memory slots | 2x DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
| Storage | |
| Storage media | HDD |
| Number of storage drives installed | 1 |
| Number of hard drives installed | 1 |
| Hard drive capacity | 1000 GB |
| Hard drive speed | 7200 RPM |
| Hard drive interface | Serial ATA |
| Card reader integrated | Yes |
| Compatible memory cards | MS PRO, Memory Stick (MS), SD, SDHC, SDXC |
| Total storage capacity | 1000 GB |
| Graphics | |
| Discrete graphics adapter | No |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| On-board graphics adapter base frequency | 350 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter ID | 0x5912 |
| On-board graphics adapter | Yes |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter model | Intel HD Graphics 630 |
| Optical drive | |
| Optical drive type | DVD Super Multi |
| Optical drives quantity | 1 |
| Networking | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| Combo headphone/mic port | No |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| DC-in jack | No |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Technical details | |
| Water cooling system | No |
| Intel 64 | Yes |
| Product type | PC |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Colour of product | Black |
| Chassis type | Desktop |
| Placement supported | Vertical |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel H270 |
| Design | |
| Water cooling system | No |
| Colour of product | Black |
| Chassis type | Desktop |
| Placement supported | Vertical |
| Performance | |
| Embedded options available | No |
| Product type | PC |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel H270 |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Home |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® Secure Key | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Thermal solution specification | PCG 2015C |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Scalability | 1S |
| Processor package size | 37.5 x 37.5 |
| Processor code | SR35C |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 97455 |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Power | |
| Power supply input frequency | 50/60 |
| Power supply input voltage | 100 - 240 |
| Power supply | 180 W |
| Operational conditions | |
| Operating altitude | 0 - 120078.7" (0 - 3050 m) |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 10 - 40 °C |
| Non-operating altitude | 0 - 179921.3" (0 - 4570 m) |
| Certificates | |
| RoHS compliance | Yes |
| EPEAT compliance | Silver |
| Energy Star certified | Yes |
| Weight & dimensions | |
| Width | 12.4" (315 mm) |
| Depth | 6.42" (163 mm) |
| Height | 12.1" (307 mm) |
| Weight | 12.6 lbs (5.7 kg) |
| Packaging content | |
| Mouse included | Yes |
| Display included | No |
| Keyboard included | No |
| Other features | |
| On-board graphics adapter | Yes |
