Product Description
| Processor | |
|---|---|
| Stepping | R0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Broadwell |
| Bus type | QPI |
| Maximum internal memory supported by processor | 1536 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133,2400 MHz |
| Thermal Design Power (TDP) | 140 W |
| Tcase | 69 °C |
| Processor series | Intel Xeon E5-1600 v4 |
| PCI Express configurations | 1x16,1x4,1x8 |
| Maximum number of PCI Express lanes | 40 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Memory channels supported by processor | Quad |
| ECC supported by processor | Yes |
| Processor cache type | Smart Cache |
| Conflict Free processor | Yes |
| Processor cache | 10 MB |
| Processor frequency | 3.70 GHz |
| Processor model | E5-1630V4 |
| Number of processors installed | 1 |
| Processor boost frequency | 4.00 GHz |
| Processor socket | LGA 2011-v3 |
| Processor threads | 8 |
| Processor cores | 4 |
| PCI Express slots version | 3.0 |
| Processor family | Intel Xeon E5 v4 |
| Memory | |
| Internal memory | 8 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| Maximum internal memory | 128 GB |
| Memory slots | 8x DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
| Storage | |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| RAID support | Yes |
| Solid-state drive capacity | 256 GB |
| RAID levels | 0, 1, 10 |
| Number of SSDs installed | 1 |
| Total storage capacity | 256 GB |
| Software | |
| Drivers included | Yes |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 7 Professional |
| Graphics | |
| On-board graphics adapter | No |
| On-board graphics adapter model | Not available |
| Optical drive | |
| Optical drive type | DVD Super Multi |
| Optical drives quantity | 1 |
| BD interface type | SATA |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 8 |
| USB 2.0 ports quantity | 2 |
| PS/2 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI slots | 1 |
| PCI Express x8 slots | 1 |
| PCI Express x4 slots | 1 |
| PCI Express x16 slots | 2 |
| PCI Express x1 slots | 1 |
| PCI Express slots version | 3.0 |
| Technical details | |
| Intel 64 | Yes |
| Product type | Workstation |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Chassis type | Tower |
| Number of 5.25" bays | 2 |
| Number of 3.5" bays | 2 |
| Motherboard chipset | Intel C612 |
| Design | |
| Chassis type | Tower |
| Number of 5.25" bays | 2 |
| Number of 3.5" bays | 2 |
| Performance | |
| Embedded options available | No |
| Audio chip | Realtek ALC221 |
| Product type | Workstation |
| Motherboard chipset | Intel C612 |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Secure Key | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Intel Flex Memory Access | No |
| Intel Enhanced Halt State | Yes |
| Intel Demand Based Switching | Yes |
| Supported instruction sets | AVX 2.0 |
| Scalability | 1S |
| Processor package size | 45 x 52.5 |
| Processor code | SR2PF |
| Physical Address Extension (PAE) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 92987 |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Physical Address Extension (PAE) | 46 bit |
| Power | |
| Power supply | 700 W |
| Weight & dimensions | |
| Width | 6.65" (169 mm) |
| Depth | 17.5" (445 mm) |
| Height | 17" (432 mm) |
| Weight | 24.3 lbs (11 kg) |
| Packaging content | |
| Manual | Yes |
| Drivers included | Yes |
| Display included | No |
| Other features | |
| On-board graphics adapter | No |
