Product Description
Specifications- Mfr Part Number: EXPI9404PTLBLK LOW PROFILE
- Features:
- Two Intel 82571GB Gigabit Controllers
- Low-profile
- Load balancing on multiple CPUs
- Intel I/OAT
- Virtualization
- Interrupt moderation
- Compatible with x4, x8, and x16 full-height PCI-Express slots
- Support for most network operating systems (NOS)
- Remote management support
- Category-5 unshielded twisted pair (UTP), 4-pair cabling
- RoHS compliant, lead-free technology
- Intel PROSet Utility for Windows
- Advanced cable diagnostics
- Intel backing
- Connectors: 4x RJ-45
- IEEE standards/network topology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Wiring: Category-5, unshielded twisted pair (UTP), 4-pair
- Network Management:
- Wired for Management (WfM) baseline v2.0 enabled for servers
- DMI 2.0 support, Windows Management Instrumentation (WMI) and SNMP-manageable SMBus support
- Remote Installation Services (RIS)
- Diagnostics (loopback, testability, PHY register access)
- Advanced configuration and power interface (ACPI) 1.0 power management
- Wake on LAN support over PCI-Express
- PXE 2.0 enabled through boot read-only memory (ROM)
- Advanced Software Features:
- Adapter fault tolerance (AFT)
- Switch fault tolerance (SFT)
- Adaptive load balancing (ALB)
- Fast EtherChannel (FEC)
- Gigabit EtherChannel (GEC)
- Teaming support: Scales upto 8 connections
- Multiple teams: Supports 4 separate teams, maximum
- IEEE 802.3ad (link aggregation control protocol)
- Test switch configuration: Tested with major switch original equipment manufacturers (OEMs)
- PCIe Hot Plug/Active peripheral component interconnect (PCI)
- IEEE 802.1Q VLANs
- IEEE 802.3 (z, ab, u, x) flow control support
- TCP checksum offload - transmission control protocol (TCP), user datagram protocol (UDP), Internet protocol (IP)
- IEEE 802.1p
- TCP segmentation/large send offload
- Interrupt moderation
- Controller-processor: Intel 82571GB
- Data rate(s) supported per port: 10, 100, and 1000 Mbps
- Bus type: PCI-Express 1.0a
- Bus width: x4 lane PCI-Express, operable in x4, x8, x16 slots
- Bus speed (x4, encoded rate): 10 Gbps uni-directional; 20 Gbps bi-directional
- EEPROM-SPI and single EEPROM support
- Interrupt levels: INTA, INTB, INTC, INTD
- IEEE support: 802.3ab
- LEDs: 4 (1/port, link and speed) solid and blinking
- Typical power consumption: 4.95W (3.3 V @ 1.5 A)
- Hardware certifications: FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
- Dimensions (WxLxH): 0.75 x 6.6 x 2.35 inch / 1.91 x 16.76 x 5.97 cm
