Product Description
Motherboard | |
---|---|
Motherboard form factor | UCFF |
Processor socket | BGA 1090 |
Number of processors supported | 1 |
Processor | |
Thermal Design Power (TDP) | 10 W |
L3 cache | 4 MB |
Built-in processor | Yes |
Processor model | J5005 |
Processor boost frequency | 2.80 GHz |
Processor threads | 4 |
Processor frequency | 1.50 GHz |
Processor socket | BGA 1090 |
Processor lithography | 14 nm |
Processor cores | 4 |
Processor family | Intel Pentium Silver |
Number of processors supported | 1 |
Memory | |
Memory voltage | 1.2 V |
Memory slots type | SO-DIMM |
Number of memory slots | 2 |
Memory channels | Dual |
Memory bandwidth (max) | 38.4 GB/s |
Supported memory types | DDR4-SDRAM |
Supported memory clock speeds | 2400 MHz |
Maximum internal memory | 8 GB |
Non-ECC | Yes |
Video | |
On-board graphics adapter | Yes |
Graphics adapter | Intel UHD Graphics 605 |
Graphics adapter family | Intel |
Storage | |
Supported storage drive types | HDD, SSD |
Storage drive sizes supported | 2.5" |
Storage drive interface | Serial ATA III |
Number of storage drives supported | 1 |
Compatible memory cards | SDXC |
Card reader integrated | Yes |
Graphics | |
On-board graphics adapter | Yes |
Graphics adapter | Intel UHD Graphics 605 |
Graphics adapter family | Intel |
Audio | |
Intel® High Definition Audio (Intel® HD Audio) | Yes |
Audio output channels | 7.1 channels |
Networking | |
Wi-Fi standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
Bluetooth | Yes |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Ports & interfaces | |
Number of SATA III connectors | 1 |
Infrared data port | Yes |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 4 |
S/PDIF out port | Yes |
HDMI ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Expansion slots | |
PCI Express slots version | 2.0 |
Design | |
Motherboard form factor | UCFF |
Product type | Mini PC barebone |
On/off switch | Yes |
LED indicators | Yes |
Colour of product | Black |
Chassis type | UCFF |
Performance | |
Trusted Platform Module (TPM) | No |
Processor special features | |
Intel® Smart Response Technology | No |
Intel® Secure Key | Yes |
Thermal Monitoring Technologies | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® Turbo Boost Technology | No |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel 64 | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel® vPro™ Technology | No |
Intel® Anti-Theft Technology (Intel® AT) | No |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Embedded options available | Yes |
Colour | |
Colour of product | Black |
Technical details | |
Intel® vPro™ Technology | No |
Intel® Anti-Theft Technology (Intel® AT) | No |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel® High Definition Audio (Intel® HD Audio) | Yes |
Embedded options available | Yes |
Trusted Platform Module (TPM) | No |
Processor cores | 4 |
Chassis type | UCFF |
ARK ID | 126137 |
Indication | |
LED indicators | Yes |
Management features | |
On/off switch | Yes |
Power | |
AC adapter output voltage | 12-19 |
Power supply type | External AC adapter |
Other features | |
Embedded options available | Yes |
Chassis type | UCFF |
