Product Description
| Processor | |
|---|---|
| Thermal Monitoring Technologies | Yes |
| Thermal Design Power (TDP) | 72 W |
| Processor threads | 8 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Skylake |
| Memory types supported by processor | DDR3L-SDRAM,DDR4-SDRAM |
| Memory clock speeds supported by processor | 1866,2400 MHz |
| Memory channels supported by processor | Dual |
| Memory bandwidth supported by processor (max) | 37.5 GB/s |
| Maximum number of PCI Express lanes | 16 |
| Maximum internal memory supported by processor | 64 GB |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Processor frequency | 3.5 GHz |
| Number of processors installed | 1 |
| Processor model | E3-1230V6 |
| Processor boost frequency | 3.9 GHz |
| System bus rate | 8 GT/s |
| Processor socket | LGA 1151 (Socket H4) |
| Processor cores | 4 |
| Motherboard chipset | Intel C232 |
| Processor family | Intel Xeon E3 v6 |
| Memory | |
| Internal memory | 8 GB |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 4 |
| Memory clock speed | 2400 MHz |
| Maximum internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Storage | |
| RAID support | Yes |
| Hard drive interface | Serial ATA, Serial Attached SCSI (SAS) |
| Graphics | |
| On-board graphics adapter model | Aspeed AST2400 |
| On-board graphics adapter | Yes |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 4 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 3 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Optical drive type | No |
| Chassis type | Rack (1U) |
| Performance | |
| Compatible operating systems | Microsoft Windows 10; Microsoft Windows Server 2012 R2 and 2016; Red Hat Enterprise Linux (RHEL) Server 7; SUSE Linux Enterprise Server (SLES) 11 and 12; VMware vSphere (ESXi) 6.0 and 6.5. |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Operating system installed | No |
| BIOS type | UEFI |
| Display | |
| Built-in display | No |
| Processor special features | |
| Intel® Wireless Display (Intel® WiDi) | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel Clear Video Technology | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 8 - 80% |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating altitude | 0 - 120000" (0 - 3048 m) |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Trusted Platform Module (TPM) | Yes |
| Ethernet interface type | Gigabit Ethernet |
| BIOS type | UEFI |
| Chassis type | Rack (1U) |
| Software | |
| Compatible operating systems | Microsoft Windows 10; Microsoft Windows Server 2012 R2 and 2016; Red Hat Enterprise Linux (RHEL) Server 7; SUSE Linux Enterprise Server (SLES) 11 and 12; VMware vSphere (ESXi) 6.0 and 6.5. |
| Operating system installed | No |
| Weight & dimensions | |
| Width | 17.3" (439 mm) |
| Height | 1.69" (43 mm) |
| Depth | 16.2" (411 mm) |
