Product Description
Specifications
- Mfr Part Number: NP-ME361W
- Optical:
- Display Technology: 0.59" LCD w/ MLA
- Light Output (Lumens): 3600 normal
- Resolution:
- Native: WXGA 1280 x 800
- Maximum: WUXGA 1920 x 1200
- Native: WXGA 1280 x 800
- Contrast Ratio (typical): 6,000:1
- Lamp Type: 240W AC
- Lamp Life (up to): 4000 hours normal / 9000 hours eco
- Screen Size (Diagonal): 30 ~ 300 inch / 0.76 ~ 7.62 m
- Throw Ratio: 1.3 ~ 2.2:1
- Projection Distance: 2.3 ~ 47.9 ft / 0.7 ~ 14.6 m
- Projector Angle: 6.5 ~ 6.8° tele / 10.7 ~ 11.4° wide
- Lens:
- Zoom: 1.7
- Focus: Manual
- F-number, f-number: F= 1.7 ~ 2.1 mm, f= 17.5 ~ 29.0 mm
- Zoom: 1.7
- Keystone Correction: +/- 30° horizontal, +/- 30° vertical
- Display Technology: 0.59" LCD w/ MLA
- Signal Compatibility/Connectivity:
- Synchronization Range:
- Horizontal (Analog/Digital): Analog - 15 ~ 100kHz, Digital - 15 ~ 153kHz
- Vertical (Analog/Digital): Analog - 48 ~ 120Hz, Digital - 24 ~ 120Hz
- Horizontal (Analog/Digital): Analog - 15 ~ 100kHz, Digital - 15 ~ 153kHz
- Supported Video Standards: NTSC, NTSC 4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM
- SD/HD Video Signal Compatibility: Y/CB/Cr component (with optional adaptor ADP-CV1E) 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
- PC Signal Compatibility: VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA
- Macintosh Compatibility: Yes
- Input/Output Terminals:
- RGB1 (Analog): VGA 15-pin D-sub
- RGB3 (Digital): HDMI w/ HDCP
- RGB4 (Digital): HDMI w/ HDCP
- RGB5 (Digital): USB A Type
- Video 1: RCA
- Audio 1: L/R RCA (shared by video sources)
- Audio 2: 1/8 inch stereo
- Monitor Out: VGA 15-pin D-sub
- Audio Out: Yes (variable)
- RGB1 (Analog): VGA 15-pin D-sub
- Audio: 20W speaker
- External Control: RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional)
- Sync Compatiblity: Separate Sync/ Composite Sync/ Sync on G
- Synchronization Range:
- Electrical:
- Power Requirements: 100~240V AC, 50/60Hz
- Input Current: 3.4A / 1.4A
- Power Consumption (Normal/ ECO Mode/ Standby/ Standby Power Saving): 309W / 201W / 1.9W / 0.23W
- Power Requirements: 100~240V AC, 50/60Hz
- Installation Orientation: Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear
- Fan Noise: 36 dB (normal)/ 29 dB (eco)
- Regulations: USA - UL (UL60950-1) FCC Part15 Class B; Canada - C-UL (CSA60950-1) ICES-003 Class B, NOM
- Dimensions: 13.4 x 10.2 x 4.2 inch / 339.0 x 259.0 x 109.0 mm
- Weight: 6.4 lbs / 2.9 kg
