Product Description
Specifications
- Mfr Part Number: TVS-463-8G-US
- Hardware:
- CPU: AMD x86 Processor (2.4GHz, Quad-Core), with Radeon graphics
- Memory: 8GB DDR3L-1600 RAM (expandable up to 16GB)
- Flash Memory: 512 MB DOM
- HDD Capacity: 4x 3.5" or 2.5" SATA3/SATA2 Hard Drive or SSD
- HDD Tray: 4x Hot-swappable Trays
- LAN Port: 2x Gigabit RJ45 Ethernet Ports (Onboard:2, expandable to max 4 ports via PCI-E NIC)
- Slot: 1x PCI-Express 2.0 x4 Slot
- LCD Panel: Mono-LCD display with backlight, Enter and Select buttons for configuration
- LED Indicators: Power, Status, LAN, USB, HDD 1-4
- USB: 5x USB 3.0 Ports (4 rear, 1 front), Support USB printer, pen drive, and USB UPS etc.
- HDMI: 2 (Mirrored Display), 1.4a
- Buttons: Power/Status, USB One-Touch-Backup, reset
- Alarm Buzzer: System Warning
- IR Receiver: QNAP RM-IR002 and MCE-compatible remotes
- Secure Design: Kensington security slot for theft prevention
- Operating System: QTS 4.1 (Embedded Linux)
- Networking:
- TCP/IP (IPv4 & IPv6: Dual Stack)
- Dual Gigabit NICs with jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)
- Service binding based on network interfaces
- Proxy server (Squid available in App Center)
- Proxy client
- DHCP client, DHCP server
- Protocols - CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
- UPnP & Bonjour Discovery
- USB Wi-Fi 802.11ac adapter support
- Security:
- Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
- CIFS host access control for shared folders
- FIPS 140-2 validated AES 256-bit volume-based data encryption
- AES 256-bit external drive encryption
- Importable SSL certificates
- Instant alert via email, SMS, beep, and LCD panel
- Storage Management:
- QNAP flexible Volume/LUN with thin provisioning and space reclaim
- RAID 0,1, 5, 6, 10, 5/6/10 + hot spares
- Supports storage pool
- Online volume expansion
- Online storage pool expansion
- Online RAID capacity expansion and online RAID level migration
- SMART data migration
- Storage expansion via QNAP UX-500P/UX-800P expansion units
- Bad block scan and hard drive S.M.A.R.T.
- Bad block recovery
- RAID recovery
- Bitmap support
- File System:
- Internal HDD: EXT4
- External HDD: EXT3, EXT4, NTFS, FAT32, HFS+
- Backup Station:
- Remote replication server (over rsync)
- Real-time remote replication (RTRR) to another QNAP NAS or FTP server
- Works as both RTRR server & client with bandwidth control
- Real-time & scheduled backup
- Encryption, compression, file filters, and transfer rate limitations
- Encrypted replication between QNAP NAS servers
- Desktop backup with QNAP NetBak Replicator for Windows
- Apple Time Machine backup support
- Data backup to multiple external storage devices
- Synchronizes with cloud storage: Amazon S3, ElephantDrive, Symform, Dropbox, and Google Drive
- Third party backup software support: Veeam backup & replication, Acronis True Image, Arcserve backup, emc retrospect, Symantec Backup Exec, etc.
- Application:
- File Server
- VPN Server
- FTP Server
- VPN Client
- HD (Hybrid Desk) Station
- Transcode Management
- Cloud Storage Backup
- Print Server
- Storage Plug & Connect
- Signage Station
- iSCSI (IP Scan)
- iTunes Server
- Virtualization Station
- AirPlay & Chromecast
- Surveillance Station
- Notes Station
- DLNA Server
- App Center
- Form Factor: Tower
- Fan: 1x 12cm 12V DC quiet cooling fan
- Power Consumption:
- S3 Sleep: 2.26W
- HDD Standby: 34.77W
- In Operation: 50.38W (with 4x 2TB HDDs installed)
- Power Supply: ATX 250W, 110-240V AC, 50-60Hz, 5A
- Dimensions (WxDxH): 7.09 x 9.25 x 6.97 inch / 180.0 x 235.0 x 177.0 mm
- Weight: 10.05 lbs / 4.56 kg
