Product Description
Specifications
- Mfr Part Number: TVS-EC1080-E3-16G-US
- Hardware:
- CPU: Intel Xeon E3-1245 v3 Processor (3.4GHz, Quad-Core)
- Memory: 16GB DDR3 Non-ECC RAM, Expandable up to 32GB (4x 8GB)
- Flash Memory: 512MB DOM
- Internal Cache Port: Two mSATA port on board for read caching
- HDD Capacity: 10x 3.5" SATA 6Gb/s, 3Gb/s Hard Drives or 2.5" SATA 6Gb/s, 3Gb/s Hard Drive SSD
- HDD Tray: 10x Hot-swappable & Lockable Trays
- LAN Port: 4x Gigabit RJ45 Ethernet Ports
- LED Indicators: Status, LAN, USB, eSATA and 10GbE
- USB: 3x USB 3.0 Ports (1 front, 2 rear), 6x USB 2.0 Ports (rear); Support USB printer, pen drive, USB hub, and USB UPS etc.
- Buttons: Power Button, Reset Button
- Alarm Buzzer: System Warning
- Expansion Slot: 1 (1x PCI-Express 3.0 x8)
- Sound Level:
- Standby: 30.4dB
- In Operation: 31.6 dB (w/ 10x 1TB hard drives installed)
- Operating System: QTS 4.1 (Embedded Linux)
- Networking:
- TCP/IP (IPv4 & IPv6 - Dual Stack)
- Quad Gigabit NICs with Jumbo Frame
- Failover
- Multi-IP Settings
- Port Trunking/NIC Teaming (Modes - Balance-RR, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
- Service Binding Based on Network Interfaces
- Proxy Client, Proxy Server
- DHCP Client, DHCP Server
- Protocols - CIFS/SMB, AFP (v3.3), NFS (v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
- UPnP & Bonjour Discovery
- USB Wi-Fi Adapter Support
- Security:
- IP Filter & Policy-based Automatic IP Blocking
- Network Access Protection with Auto-blocking - SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
- Encrypted Access - HTTPS, FTP with SSL/ TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication (Rsync over SSH)
- CIFS Host Access Control for Shared Folders
- Antivirus Protection
- FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption
- AES 256-bit External Drive Encryption
- Importable SSL Certificate
- Instant Alert via E-mail, SMS, Beep, and LCD Panel
- Disk Management:
- QNAP Flexible volume
- Thin-provisioning with space reclamation supported
- Online Volume Expansion
- Online Storage Pool Expansion (via QNAP RAID expansion enclosure)
- Single Disk, JBOD, RAID 0, 1, 5, 6, 10
- RAID Hot Spare and Global Hot Spare
- Online RAID Capacity Expansion and Online RAID Level Migration
- Bad Block Scan and Hard Drive S.M.A.R.T.
- Bad Block Recovery
- RAID Recovery
- Bitmap Support
- File System:
- Internal HDD: EXT4
- External HDD: EXT3, EXT4, NTFS, FAT32, HFS+
- Backup Station:
- Remote Replication Server (over Rsync)
- Real-time Remote Replication (RTRR) to another QNAP NAS or FTP Server
- Works as Both RTRR Server & Client with Bandwidth Control
- Real-time & Scheduled Backup
- Encryption, Compression, File Filter, and Transfer Rate Limitation
- Encrypted Replication between QNAP NAS Servers
- Desktop Backup by QNAP NetBak Replicator for Windows
- Apple Time Machine Support with Backup Management
- Data Backup to Multiple External Storage Devices
- Synchronizes with Cloud Storage - Amazon S3, ElephantDrive, Symform, Dropbox, and Google Drive
- Third Party Backup Software Support - Veeam Backup & Replication, Acronis True
- Image, ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper, etc
- Form Factor: Tower
- Fan: 2x 12cm Smart Cooling Fans
- Power Supply:
- Input: 100-240V AC, 50/60Hz
- Output: 350W
- Power Consumption:
- Sleep Mode: 68W
- In Operation: 130W (w/ 10x 1TB hard drives installed)
- Dimensions (WxDxH): 12.80 x 12.65 x 8.56 inch / 327.0 x 321.2 x 217.5 mm
- Weight: 27.61 lbs / 12.52 kg
