Product Description
Specifications
- Mfr Part Number: M12II 520 BRONZE
- Features:
- 80PLUS Bronze Certified High Efficiency
- Highly Reliable 105Ìâå¡C Japanese Brand Capacitor
- Ample +12V Outputs
- Active Power Factor Correction [99% PF Typical]
- Double Forward Converter Design
- Smart & Silent Fan Control
- 12cm Ball Bearing Cooling Fan
- Soft-Mount Rubber Cushions
- Universal Video Card Support
- All-in-One DC Cabling Design
- Detachable Modular Cables
- Patented Easy Swap Connector
- Universal AC Input [Full Range]
- Ultra Ventilation [Honeycomb Structure]
- Over Voltage / Over Power / Short Circuit Protection
- 80 PLUS Bronze Certified
- AMD Game Ready
- 80PLUS Bronze Certified High Efficiency
- Total Power: 520 W
- Input Voltage: 100~240 V
- Input Frequency Range: 50 / 60 Hz
- Power Factor Correction: Active PFC
- Output: +3.3V@24A, +5V@24A, +12V1@20A, +12V2@20A, -12V@0.8A, +5VSB@2.5A
- Connector: 1x 20+4pin Main Power; 1x 4/8pin 12V CPU Power; 1x 8pin 12V CPU Power; 6x SATA; 6x Peripheral; 1x 6pin PCI-Express; 1x 6+2pin PCI Express; 2x 4pin Floppy
- Cooling System: 120mm cooling Fan
- Dimension (WxLxH): 5.9 x 6.9 x 3.4 inch / 150 x 160 x 86 mm
- RoHS Compliant
