Product Description
Specifications
- Mfr Part Number: SSP-300SFG
- Features:
- SATA-ready
- DC to DC converter design
- High efficiency and reliability
- Low ripple and noise
- Super low noise fan control (S2FC)
- Short circuit protection on all outputs
- Over voltage protection
- Over power protection
- 100 % HiPot test
- 100 % Burn-in, high temperature cycled on/off
- Type: SFX 12 V v.2.31
- Total Power: 300 W
- Input:
- Current: 100A max
- Frequency: 50 / 60 Hz
- Current: 100A max
- Ì¢‰â‰Û?Power Factor Correction: 99 % (typical)
- Efficiency: >=87% (at normal input voltage)
- MTBF: >100,000 hours
- Output: +3.3V @ 10A, +5V @ 14A, +12V (combined) @ 25A, -12V @ 0.3A, +5Vsb @ 2A
- Connector: Main Power Connector, ATX 12V Connector, SATA Connector, HDD Connector, FDD Connector
- Safety and EMI/EMC: CUL, TUV, CB, CCC, BSMI, CE, FCC, C-tick
- Dimensions (WxLxH): 100.0 x 125.0 x 63.5 mm
