Product Description
Specifications
- Mfr Part Number: SYS-5017C-LF
- Motherboard: Super X9SCL-F
- Processor: LGA1155
- Supports Intel Xeon E3-1200 &v2 Series Processors
- Supports 3rd and 2nd Generation Intel Core i3/ Pentium/ Celeron Processors
- Supports up to 45W TDP
- Chipset: Intel C202 PCH
- Memory: 4x 240pin DDR3-1333/1066/800 DIMM Slots, Supports up to 32GB ECC/Unbuffered Memory
- Slots: 1x PCI-Express 2.0 x8 Slot (Low-profile)
- SATA: 6x SATA2 Ports, Support RAID 0, 1, 5, 10
- Video: Nuvoton WPCM450RA0BX Graphics
- LAN: Intel 82574L and 82579LM Gigabit Ethernet Controllers; 1x Realtek RTL8201N PHY (dedicated IPMI)
- Drive Bays: 1x 3.5" Hard Drive Bays
- Backplane: SAS/SATA HDD Backplane (SAS support requires optional SAS controller)
- Ports: 9x USB 2.0 Ports(2 rear, 6 via headers, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 1U Rackmount
- Power Supply: 200W Low Noise AC-DC Power Supply w/ PFC
- System Cooling: 2x 40x28mm 8500 RPM PWM Cooling Fans
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: Power, HDD Activity, 2x Network Activity, System Overheat
- Color: Black
- Dimensions (WxDxH): 17.2 x 11.3 x 1.7 inch / 437.0 x 287.0 x 43.0 mm
- Gross Weight: 11.0 lbs / 4.99 kg
- RoHS Compliant
