Product Description
Specifications
- Mfr Part Number: SYS-5018A-MLTN4
- Motherboard: Super A1SAM-2550F
- Processor: Intel Atom C2550 Processor, Supports up to 14W TDP (Quad-Core)
- Chipset: System-on-Chip
- Memory: 4x 240pin DDR3-1600/1333 MHz DIMM Slots, Supports up to 64GB ECC or non-ECC Memory
- Slots: 1x PCI-Express 2.0 x8 Slot (via riser)
- SATA: 2x SATA3 Ports, 4x SATA2 Ports
- Video: Integrated Aspeed AST2400 BMC Graphics
- LAN: C2000 SoC I354 Quad Gigabit Ethernet Controllers
- Drive Bays: 2x 3.5" or 4x 2.5" internal SATA2 hard drive bays (optional)
- Ports: 7x USB 2.0 Ports (4 rear, 2 via header, 1 Type A), 1x VGA Port, 2x Serial Ports (1 rear, 1 via header), 4x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN Port
- Form Factor: 1U Rackmount
- Power Supply: 200W Low Noise AC-DC power supply w/ PFC
- Front Panel:
- Buttons: Power On/Off, System Reset
- LEDs: Power, Hard Drive Activity, 2x Network Activity, System Overheat
- Color: Black
- Dimensions (WxDxH): 16.8 x 14.0 x 1.7 inch / 426.0 x 356.0 x 43.0 mm
- Weight: 8.0 lbs / 3.62 kg
- RoHS Compliant
