Product Description
Specifications
- Mfr Part Number: TL-R470T+
- Features:
- Dynamic IP, Static IP, PPPoE, L2TP, PPTP and BigPond Cable Internet connection options easily connect to Internet
- Time-based access control allows parents or administrators to establish restricted access policies for children or staff
- IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC which guarantees the performance of VoIP or video application
- Built-in DHCP server supports static IP address distribution
- Built-in firewall supports IP address filtering, Domain Name filtering, and MAC address filtering
- IP and MAC binding function effectively prevents ARP virus attacks
- Powerful DoS attack protection safeguards your network
- Virtual Server, Special Application, DMZ host and UPnP help users build their own servers
- DDNS helps users utilize remote management easily with a domain name
- Standards: IEEE 802.3, 802.3u, 802.3x
- Protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS
- Interface: 1x Fixed Ethernet WAN Port; 1x Fixed Ethernet LAN Port; 3x Changeable Ethernet WAN/LAN Ports
- Network Media:
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100ë© STP (maximum 100m)
- 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100ë© STP (maximum 100m)
- Button: Reset Button
- Software features:
- WAN Type: PPPoE, Dynamic IP, Static IP, PPTP, L2TP, Bigpond Cable
- Basic Function: DHCP Server, DHCP Client, MAC Address Modify/Clone, VPN Pass-through, Static Routing, Dynamic DNS, Port VLAN
- Multi-WAN Function: WAN Load Balancing, Detecting Online
- Quality of Service: IP and Port Based Bandwidth Control, Session Limit
- Port Forwarding: Virtual Server, Port Triggering, DMZ Host, UPnP
- Dynamic DNS: Dyndns, No-IP, PeanutHull, Comexe
- VPN Pass-Through: PPTP, L2TP, IPSec (ESP)
- Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
- Firewall Security: IP Address Filtering, MAC Address Filtering, Domain Name Filtering, DoS Protection
- Management: Web Management, Port Mirror, Restore & Backup Configuration, Remote Web Management
- Certification: FCC, CE, RoHS
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7; MAC OS, NetWare, UNIX or Linux
- Power Supply: AC 100-240V ~ 50/60Hz Input
- Package Contents: TL-R470+, Power cord, RJ-45 Ethernet Cable, WAN/LAN Ports Configuration Guide, Resource CD
- Dimensions (WxDxH): 209.0.0 x 126.0 x 26.0 mm
