Product Description
Specifications
- Mfr Part Number: TEG-S81G
- Features:
- GREENnet technology reduces power consumption when:
- Ethernet port is not in use
- Connected device is turned off
- Connected device is in power-saving mode
- Based on Ethernet cable length
- Store-and-Forward switching architecture with non-blocking wire-speed performance
- IEEE 802.3x Flow Control for full-duplex mode
- Back pressure Flow Control for half-duplex mode
- 8 K absolute MAC address table
- Operates and maximizes packet filtering and forwarding rate
- IEEE 802.3az Energy Efficient Ethernet technology
- Plug & Play
- GREENnet technology reduces power consumption when:
- Standards:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3x Flow Control
- IEEE 802.3az Energy Efficient Ethernet
- Network Media:
- Ethernet: Cat. 5 up to 100 m
- Fast Ethernet: Cat. 5 up to 100 m
- Gigabit Ethernet: Cat. 5, 5e, 6 up to 100 m
- Data Transfer Rates:
- Ethernet: 10Mbps/20Mbps (half/full-duplex)
- Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
- Gigabit Ethernet: 2000Mbps (full-duplex)
- Protocol/Topology: CSMA/CD, Star
- Switch Fabric: 16 Gbps forwarding capacity
- Interface: 8x Gigabit Auto-MDIX RJ-45 Ports
- Data RAM Buffer: 256 KBytes
- Filtering Table: 8 K entries
- Jumbo Frame Support: Up to 9216 Bytes
- Diagnostic LEDs: Power, Link/ACT, 100Mbps/1000Mbps
- Power Consumption: 3.5 Watts (max)
- Power Adapter:
- Input: 100~240V, 50/60Hz, 190mA
- Output: 5V DC, 1A External Power Adapter
- Certifications: FCC, CE
- Dimensions: 6.7 x 3.9 x 1.2 inch / 171.0 x 100.0 x 31.0 mm
- Weight: 6.8 oz / 190.0 g
- Package Contents: TEG-S81G, Multi-Language Quick Installation Guide, Power Adapter (5V DC, 1A)
- RoHS Compliant
