Product Description
Specifications
Manufacturer: Tripp Lite
Manufacturer Part Number: PDUMH20NET
Manufacturer Website Address: http://www.tripplite.com
Brand Name: Tripp Lite
Product Series: Switched Metered
Product Model: PDUMH20NET
Product Name: Switched Metered PDUMH20NET 16-Outlets PDU
Marketing Information: Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch breakers trip.
Product Type: PDU
Technical Information
Input Receptacles: NEMA L5-20P
Output Receptacles: 16 x NEMA 5-15/20R
Power Description
Input Voltage: 120 V AC
Output Voltage: 120 V AC
Management
Management:
Physical Characteristics
Mounting Orientation: Vertical
Placement:
Rack Height: 1U
Height: 1.8"
Width: 17.5"
Depth: 15.5"
Weight (Approximate): 12.50 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS
Manufacturer: Tripp Lite
Manufacturer Part Number: PDUMH20NET
Manufacturer Website Address: http://www.tripplite.com
Brand Name: Tripp Lite
Product Series: Switched Metered
Product Model: PDUMH20NET
Product Name: Switched Metered PDUMH20NET 16-Outlets PDU
Marketing Information: Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch breakers trip.
Product Type: PDU
Technical Information
Input Receptacles: NEMA L5-20P
Output Receptacles: 16 x NEMA 5-15/20R
Power Description
Input Voltage: 120 V AC
Output Voltage: 120 V AC
Management
Management:
Protocols:
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- Telnet
- FTP
- DHCP
- BOOTP
- NTP
Physical Characteristics
Mounting Orientation: Vertical
Placement:
- Rack
- Wall
Rack Height: 1U
Height: 1.8"
Width: 17.5"
Depth: 15.5"
Weight (Approximate): 12.50 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS
