Product Description
Manufacturer: Tripp Lite
Manufacturer Part Number: PDUMNH30HVAT
Manufacturer Website Address: http://www.tripplite.com
Brand Name: Tripp Lite
Product Series: Monitored
Product Model: PDUMNH30HVAT
Product Name: PDUMNH30HVAT 5.8kW Single-Phase 208/240V ATS/Monitored PDU
Marketing Information: The PDUMNH30HVAT 5.8kW Single-Phase 208/240V ATS/Monitored PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms, it mounts in 1U of space in EIA-standard 19-inch racks and features one L6-30R outlet-perfect for connecting a single device or a 0U 208/240V PDU with an L6-30P plug.
Dual 10-foot input cords with L6-30P plugs connect to separate primary and secondary single-phase power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1-5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.
Built-in LX Platform network management interface card. The Java-free LX Platform HTML5-based network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Automated alerts help prevent accidental overloads, power loss and downtime. Digital display indicates power availability, voltage, source A/B input status, output load and power factor, as well as temperature and humidity conditions with the optional ENVIROSENSE module (sold separately).
Product Type: PDU
Technical Information
Input Receptacles: 2 x NEMA L6-30P
Output Receptacles: 1 x NEMA L6-30R
Power Description
Input Voltage: 230 V AC
Output Voltage: 230 V AC
Power Rating (Watt): 5800 W
Input Current: 30 A
Management
Management: Protocols:
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- SNMPv3
- Telnet
- SSH
- FTP
- DHCP
- BOOTP
- NTP
Physical Characteristics
Placement: Rack
Rack Height: 1U
Height: 1.7"
Width: 16.9"
Depth: 14"
Weight (Approximate): 15.37 lb
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification: RoHS
