Product Description
| Management features | |
|---|---|
| Switch type | Managed network switch |
| Quality of Service (QoS) support | Yes |
| MIB support | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Networking | |
| Networking standards | IEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3az,IEEE 802.3u,IEEE 802.3z |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| IGMP snooping | Yes |
| Flow control support | Yes |
| DHCP server | Yes |
| DHCP client | Yes |
| Broadcast storm control | Yes |
| 10G support | No |
| Data transmission | |
| Throughput | 14.88 Mpps |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Number of VLANs | 256 |
| Jumbo frames support | Yes |
| Security | |
| Static port security | Yes |
| Security algorithms | 802.1x RADIUS |
| IGMP snooping | Yes |
| Protocols | |
| Management protocols | IGMP, SNMP |
| Switching protocols | STP, LACP, IPv6 |
| Data link protocols | TFTP, HTTP |
| Design | |
| Colour of product | Black |
| LED indicators | Activity, Link, PoE |
| Certification | UL, CSA, CE, FCC |
| Rack mounting | Yes |
| Performance | |
| Packet buffer memory | 4 MB |
| Mean time between failures (MTBF) | 287436 h |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Firmware upgradeable | Yes |
| Power | |
| AC input voltage | 100-240 |
| AC input frequency | 50/60 |
| Power consumption (typical) | 13.48 W |
| Input current | 2.5 |
| Energy Star certified | No |
| Technical details | |
| Colour of product | Black |
| Mean time between failures (MTBF) | 287436 h |
| Firmware upgradeable | Yes |
| Rack mounting | Yes |
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 62 W |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) | Yes |
| Certificates | |
| Energy Star certified | No |
| Certification | UL, CSA, CE, FCC |
| Memory | |
| Packet buffer memory | 4 MB |
| Internal memory | 128 MB |
| Flash memory | 16 MB |
| Indication | |
| LED indicators | Activity, Link, PoE |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 46 BTU/h |
| Weight & dimensions | |
| Width | 11" (279.4 mm) |
| Depth | 6.69" (170 mm) |
| Height | 1.75" (44.5 mm) |
| Weight | 2.78 lbs (1.26 kg) |
