Product Description
| Management features | |
|---|---|
| Switch type | Managed network switch |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2 |
| Ports & interfaces | |
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Gigabit Ethernet (copper) ports quantity | 4 |
| Networking | |
| Networking standards | IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| IP routing | Yes |
| IGMP snooping | Yes |
| Flow control support | Yes |
| DHCP client | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Data transmission | |
| Throughput | 77.38 Mpps |
| Number of static routes | 2048 |
| Number of IP interfaces | 256 |
| MAC address table | 16000 entries |
| Switching capacity | 120 Gbit/s |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Security | |
| SSH/SSL support | Yes |
| Security algorithms | SSH,SSL/TLS |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Protocols | |
| Management protocols | IGMP v1, 2, 3, HTTP/HTTPS, MIBs, RMON, DHCP, SCP, Textview CLI |
| Supported network protocols | Web/SSL, Telnet, SNTP, TFTP, SNMP, RADIUS, Syslog, DNS, TACACS |
| Design | |
| Form factor | 1U |
| Colour of product | Black |
| Stackable | Yes |
| LED indicators | Yes |
| Certification | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) |
| Rack mounting | Yes |
| Performance | |
| Packet buffer memory | 8 MB |
| Stackable | Yes |
| Processor frequency | 800 MHz |
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Firmware upgradeable | No |
| Power | |
| AC input voltage | 110-220 |
| AC input frequency | 50/60 |
| Power consumption (typical) | 70.5 W |
| Energy Star certified | Yes |
| Power connector | DC-in jack |
| Technical details | |
| Form factor | 1U |
| Colour of product | Black |
| Stackable | Yes |
| Processor frequency | 800 MHz |
| Firmware upgradeable | No |
| Rack mounting | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 48 |
| Total Power over Ethernet (PoE) budget | 740 W |
| Power over Ethernet (PoE) | Yes |
| Certificates | |
| Energy Star certified | Yes |
| Certification | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) |
| Memory | |
| Packet buffer memory | 8 MB |
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Indication | |
| LED indicators | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Heat dissipation | 2807.51 BTU/h |
| Weight & dimensions | |
| Width | 17.3" (440 mm) |
| Depth | 1.73" (44 mm) |
| Height | 13.8" (350 mm) |
| Weight | 12.3 lbs (5.6 kg) |
